Lithium Rotary Kiln

Model:Ø2.2×38m
Capacity:120-800t/d

Raw Materials:

Spodumene, lepidolite, lithium ore

Application:

The model of our lithium rotary kiln can meet the daily production demand of 120-800 tons.

Chat Online Leave Message

Introduction

Rotary kiln calcining lithium equipment uses lepidolite as raw material, and is carried out through mixing, roasting, cooling, crushing and other processes. Our company has been devoted to the research of lithium rotary kiln for many years, and has studied various common symptoms of the rotary kiln. It effectively solves the problems of calcium carbonate rotary kiln ring formation, low output and high energy consumption.

Application：

It is suitable for many production industries such as building materials, metallurgy, chemical industry, refractory materials, environmental protection and so on.

Product Advantages

01

The design of lithium rotary kiln fully considers the angle of the deflection support of the barrel to extend the life of refractory bricks and pouring;
02

The lithium rotary kiln adopts large diameter and small length-to-diameter ratio roller bearings to improve reliability, and the bearings are self-aligning bearings;
03

Lithium rotary kiln belongs to a new type of open gear cover sealing form with good sealing effect;
04

The spring sheet laminated flexible seal, and the double-layer spring sheet seal increases the design of the heat insulation layer, which helps to improve the reliability and service life of the lithium rotary kiln.

Parameter


Model	Feed Qiamtity（t/h）	Revolving Speed（rpm）	Qty Of Support	Reducer Model	Motor Model	Power（kW）
Ø0.8×15m	0.2~0.5	0.18~1.8	2	BWD4-43	YVFE3-132S-4	5.5
Ø2.0×36m	3~4	0.18~1.8	3	ZSY400-90	YVFE3-250M-6	37
Ø2.0×36m	3~4	0.18~1.8	3	ZSY160-25	YE3-132S-4	5.5
Ø2.6×47m	4~6	0.18~1.8	3	ZSY400-63	YVFE3-280M-6	55
Ø2.6×47m	4~6	0.18~1.8	3	ZSY160-25	YE3-132S-4	7.5
Ø3.0×54m	8~10	0.18~1.8	3	ZSY450-63	YVFE3-315M-6	90
Ø3.0×54m	8~10	0.18~1.8	3	ZSY160-25	YE3-160M-4	11
Ø3.3×60m	13~15	0.18~1.8	3	ZSY500-56	YVFE3-315L2-6	132
Ø3.3×60m	13~15	0.18~1.8	3	ZSY180-25	YE3-160M-4	11
Ø3.6×65m	20~25	0.18~1.8	3	ZSY560-63	YVFE3-355M-6	185
Ø3.6×65m	20~25	0.18~1.8	3	ZSY180-25	YE3-180M-4	18.5
Ø4.0×70m	30~35	0.18~1.8	3	ZSY630-56	YVFE3-355L-6	250
Ø4.0×70m	30~35	0.18~1.8	3	ZSY180-25	YE3-180L-4	22
Ø4.3×78m	40~45	0.18~1.8	3	ZSY630-56	YVFE3-3552-6	315
Ø4.3×78m	40~45	0.18~1.8	3	ZSY200-25	YE3-200L-4	30
Ø4.8×86m	50~60	0.18~1.8	3	MH3S240H63	YVFE3-4002-6	450
Ø4.8×86m	50~60	0.18~1.8	3	ZSY224-25	YE3-225M-4	45
Ø5.0×90m	60~70	0.18~1.8	3	MH3S250HB63	YVFE3-4002-6	500
Ø5.0×90m	60~70	0.18~1.8	3	ZSY224-25	YE3-225M-4	45
Ø5.0×100m	70~80	0.18~1.8	4	MH3S230HB71	YVFE3-3552-6	2×315
Ø5.0×100m	70~80	0.18~1.8	4	ZSY200-25	YE3-200L-4	2×30
Ø5.2×95m	70~80	0.18~1.8	4	MH3S230HB71	YVFE3-3553-6	2×355
Ø5.2×95m	70~80	0.18~1.8	4	ZSY200-25	YE3-200l-4	2×30
Ø5.2×110m	80~100	0.18~1.8	4	MH3S240HB71	YVFE3-4001-6	2×400
Ø5.2×110m	80~100	0.18~1.8	4	ZSY224-25	YE3-200L-4	2×45

Note:The lithium mica special Kiln is applicabel to the mixed burning of sulfate and lithium mica. The feeding amount varies according to the proportion of lithium mica and the level of operators. This table is noly reference. Please call us for special model selection.
